PROJECT Summary

Possible Quality Defects in Beef Caused by Multiple Applications of Antimicrobial Interventions

Principle Investigator(s):
K. B. Harris, Ph.D.
Institution(s):
Texas A&M University
Completion Date:
May 2013
Background

With the United States Department of Agriculture – Food Safety and Inspection Service (USDA-FSIS) declaration of Escherichia coli O157:H7 and Shiga-toxin producing E. coli (STEC) as adulterants in non-intact raw beef products and intact raw beef products intended for non-intact use, the addition of antimicrobial interventions has become standard procedure during beef harvest and further processing. The concept of using consecutive decontamination processes in beef packing plants as a means of improving the microbiological quality of beef carcasses is beneficial (Bacon et al., 2000) to reduce microbiological contamination of beef carcass surfaces that can occur during the beef harvest process. However, because most carcass decontamination treatments do not sterilize the carcass, microorganisms remaining on carcass surfaces can easily be transferred onto freshly cut surfaces during carcass fabrication, and subsequently carried through grinding operations (Pohlman et al., 2002).

Beef safety and quality are continuous challenges for the meat industry. With foodborne pathogens being of upmost concern, antimicrobial interventions are commonly used as a method to reduce the prevalence of pathogenic bacteria throughout the beef production process. A study conducted by Bacon et al. (2000) validated that sequential multiple hurdle interventions reduce bacteria on beef carcasses more effectively than any one intervention alone. The application of multiple interventions also can lead to the oxidation of fat and lean surfaces, which may ultimately affect the quality of ground beef products. In the past, ground beef processors have expressed concern related to the quality of beef raw materials, especially characteristics such as discoloration, off-odors, and flavors. In addition to the effectiveness of antimicrobial treatments, the impact of such treatments on meat quality factors such as color and odor (Pohlman et al., 2002) must also be considered. The objective of this research was to determine the effects of multiple applications of antimicrobial interventions on quality characteristics of beef.

Methodology

Eight universities (Texas A&M University, Texas Tech University, California Polytechnic State University, University of Florida, University of Missouri, North Dakota State University, Oklahoma State University, and Penn State University) collected 10 types of beef steaks (Top Blade, bone-in Ribeye, boneless Ribeye, bone-in Top Loin, boneless Top Loin, T-Bone, Porterhouse, Top Sirloin, Top Round, and Bottom Round) from 12 US cities (Houston, TX; Tampa, FL; Seattle, WA; New York City, NY; Denver, CO; Las Vegas, NV; Los Angeles, CA; Philadelphia, PA; Kansas City, MO; San Francisco, CA; Atlanta, GA; Chicago, IL). In each city, retail chains comprising the top 33% of the market share were identified and contacted to provide four stores to sample per chain. Additionally, one club store was sampled per city. In five cities (Houston, TX; Tampa, FL; Denver, CO; Las Vegas, NV; Philadelphia, PA), three types of beef steaks (boneless Ribeye, boneless Top Loin, Top Sirloin) were collected from a foodservice establishment. Brand designation, marketing claims, enhancement with percentage pumped, sodium content, form of tenderization, and any other important features were recorded on each steak, and each steak was measured for average external fat thickness and steak thickness. Approximately 60% of retail steaks (n = 1,319) were used for consumer sensory panels conducted at six universities, and the remainder of the retail steaks were used for Warner-Bratzler shear force. Foodservice steaks (n = 464) were divided in half and used for consumer sensory panels and Warner-Bratzler shear force. All steaks were cooked to an internal temperature of 70°C. Consumer sensory panels rated samples for overall like, overall like of tenderness, level of tenderness, overall like of flavor, level of beef flavor, overall like of juiciness, and level of juiciness. Four antimicrobial treatment combinations (hot water applied to hot carcass followed by hot carcass lactic acid application; hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter lactic acid spray; hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter acidified sodium chlorite spray; hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter Beefxide spray); in addition to a control (hot carcass lactic acid spray only), were used in this study. Following carcass treatments (Figure 1), trimmings were assigned to one of four treatment groups (acidified sodium chlorite, Beefxide, lactic acid or control). Trimmings were sprayed following forequarter fabrication, and were subsequently held in cold storage for 48 h prior to grinding. Ground beef patties were produced from each trimming subgroup (n = 40) and designated for shelf-life (Figure 2), consumer panel, or trained panel evaluation. Beef patty temperature, pH and color (L*, a*, b*) measurements were taken on the day of patty production, in addition to daily color measurements taken over the 5 d shelf-life period.

Findings

Overall, no single treatment combination appeared to significantly influence consumer perception (Figures 1, 2, and 3) or instrumental measurements (Table 1) of beef patty quality. While some visual darkening of patty color occurred by the completion of the shelf-life period, few significant changes were seen in color space values for each treatment combination (Table 2).

Implications

In general, findings from this study support that food safety interventions, while effective in reducing microbiological counts on product surfaces, do not negatively impact beef patty quality.

Table 1. Least squares means stratified by carcass and trimmings treatmentA combinations for beef patty temperature (°C), pH, and CIE color space values (L*, a*, b*).

Beef patty quality parameters

Treatment combinations

Temperature (°C)

pH

L*

a*

b*

Hot carcass lactic acid application only

Acidified sodium chloriteB

7.95bcdef

5.79ab

60.23a

17.70abc

20.55ab

BeefxideC

8.25abcd

5.69abcd

53.94de

19.45ab

19.99abc

Lactic acidD

7.40defgh

5.69cd

58.44ab

16.15c

18.13bcd

ControlE

8.85a

5.72abcd

56.08bcde

18.56abc

21.24a

Hot water applied to hot carcass followed by hot carcass lactic acid application

Acidified sodium chlorite

6.54hi

5.71abcd

58.17ab

15.73c

16.44d

Beefxide

8.58abc

5.72abcd

52.27e

19.17abc

18.40abcd

Lactic acid

8.76ab

5.74abcd

52.41e

17.75abc

18.15bcd

Control

7.54cdefg

5.78abc

55.88bcde

17.70abc

18.94abcd

Hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter lactic acid spray

Acidified sodium chlorite

5.06k

5.79abc

55.17bcde

20.10a

20.61ab

Beefxide

5.94ij

5.69bcd

58.89ab

15.70c

16.81cd

Lactic acid

8.44abc

5.63d

54.40cde

17.99abc

18.98abcd

Control

7.24efgh

5.81a

55.29bcde

17.41bc

18.16bcd

Hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter acidified sodium chlorite spray

Acidified sodium chlorite

7.06fgh

5.73abcd

56.86abcd

19.58ab

20.75ab

Beefxide

5.08jk

5.82a

55.01bcde

18.18abc

18.68abcd

Lactic acid

8.36abcd

5.70abcd

57.24abcd

18.08abc

18.93abcd

Control

8.41abc

5.67d

55.74bcde

19.57ab

20.44ab

Hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter Beefxide spray

Acidified sodium chlorite

6.72ghi

5.70abcd

58.50ab

17.80abc

19.98abc

Beefxide

8.22abcde

5.66d

57.32abc

18.31abc

19.40abc

Lactic acid

8.40abc

5.74abcd

57.53abc

19.31ab

20.55ab

Control

9.22a

5.73abcd

59.08ab

18.09abc

20.06abc

  • Means within the same column lacking a common letter (a-k) differ (P < 0.05).
  • A Following carcass treatments, trimmings were assigned to one of four treatment groups (acidified sodium chlorite, Beefxide, lactic acid or control). Trimmings were sprayed following forequarter fabrication, and were subsequently held in cold storage for 48 h prior to grinding.
  • B Acidified sodium chlorite was applied at room temperature (approximately 25°C).
  • C Beefxide was applied at approximately 55°C.
  • D Lactic acid was applied at approximately 55°C.
  • E No antimicrobial intervention was applied to control trimmings.

Table 2. Least squares means stratified by carcass and trimmings treatmentA combinations for beef patty CIE color space values (L*, a*, b*) across shelf-life days.





L*







a*







b*



Treatment combinations

d 1

d 3

d 5



d 1

d 3

d 5



d 1

d 3

d 5

Hot carcass lactic acid application only

Acidified sodium chloriteB

55.83a

55.70a

50.50b



15.79a

10.44b

13.81a



20.09ab

18.98b

20.64a

BeefxideC

53.15a

52.62a

50.93a



18.06a

11.30b

10.86b



19.56a

16.50b

18.08ab

Lactic acidD

53.04a

55.03a

52.45a



17.39a

10.57b

9.90b



19.66a

16.91b

19.03a

ControlE

55.15a

55.80a

54.03a



17.06a

11.29b

10.57b



20.10a

17.80a

20.10a

Hot water applied to hot carcass followed by hot carcass lactic acid application

Acidified sodium chlorite

50.17a

48.58a

46.92a



15.95a

10.23b

11.77b



17.94a

16.26a

18.71a

Beefxide

50.80a

49.97a

49.11a



15.36a

11.49a

11.08a



17.64a

16.50a

18.62a

Lactic acid

49.42a

51.97a

49.68a



15.60a

8.38b

10.12b



17.22ab

14.96b

17.93a

Control

51.38a

52.16a

49.00a



15.93a

8.86b

11.22b



18.73a

15.73b

19.04a

Hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter lactic acid spray

Acidified sodium chlorite

49.92a

52.58a

48.23a



17.54a

11.74b

9.38b



19.15a

17.34a

17.65a

Beefxide

49.57b

52.79a

51.44ab



14.55a

8.70b

8.61b



17.59a

16.05a

17.40a

Lactic acid

51.26a

51.35a

51.69a



14.01a

11.23ab

7.76b



17.35a

16.19a

15.54a

Control

51.17a

51.67a

50.50a



16.29a

12.26ab

9.14b



18.24a

16.77a

16.86a

Hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter acidified sodium chlorite spray

Acidified sodium chlorite

53.83a

54.31a

50.74b



17.31a

11.44b

12.90b



19.84a

17.57b

19.83a

Beefxide

52.17a

50.89ab

48.21b



17.59a

11.44c

14.39b



19.16a

16.72b

19.51a

Lactic acid

53.22a

54.43a

52.20a



17.08a

10.07b

11.82b



19.47a

16.63b

18.90a

Control

52.42a

52.51a

50.25a



17.78a

12.31b

12.05b



19.70a

17.41b

19.95a

Hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter Beefxide spray

Acidified sodium chlorite

55.80a

55.30a

53.92a



15.89a

11.08b

10.65b



19.49a

17.58a

17.99a

Beefxide

53.93a

54.47a

50.91a



16.79a

11.36b

11.65b



19.40a

17.50b

18.13ab

Lactic acid

55.89a

55.07a

53.85a



16.78a

11.49b

9.57b



19.69a

16.94b

17.96b

Control

53.22a

53.96a

53.24a



17.57a

10.66b

10.15b



20.48a

17.52b

18.67b

  • Means within the same hot carcass treatment grouping and within like CIE color space values lacking a common letter (a-c) differ (P < 0.05).
  • A Following carcass treatments, trimmings were assigned to one of four treatment groups (acidified sodium chlorite, Beefxide, lactic acid or control). Trimmings were sprayed following forequarter fabrication, and were subsequently held in cold storage for 48 h prior to grinding.
  • B Acidified sodium chlorite was applied at room temperature (approximately 25°C).
  • C Beefxide was applied at approximately 55°C.
  • D Lactic acid was applied at approximately 55°C.
  • E No antimicrobial intervention was applied to control trimmings.

Figure 3. Least squares means for consumer sensory scores of overall like (9 = like extremely; 1 = dislike extremely) for beef patties stratified by carcass treatment group (1 = control group; hot carcass lactic acid application only; 2 = hot water applied to hot carcass followed by hot carcass lactic acid application; 3 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter lactic acid spray; 4 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter acidified sodium chlorite spray; 5 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter Beefxide spray) and trimmings treatment group (A = trimmings sprayed with acidified sodium chlorite; B = trimmings sprayed with Beefxide; C = control, no antimicrobial application; L = trimmings sprayed with lactic acid). Means lacking a common letter (a-d) differ (P < 0.05).

Figure 4. Least squares means for flavor like (9 = like extremely; 1 = dislike extremely) for beef patties stratified by carcass treatment group (1 = control group; hot carcass lactic acid application only; 2 = hot water applied to hot carcass followed by hot carcass lactic acid application; 3 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter lactic acid spray; 4 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter acidified sodium chlorite spray; 5 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter Beefxide spray) x trimmings treatment group (A = trimmings sprayed with acidified sodium chlorite; B = trimmings sprayed with Beefxide; C = control, no antimicrobial application; L = trimmings sprayed with lactic acid). Means lacking a common letter (a-d) differ (P < 0.05).

Figure 5. Least squares means for consumer sensory scores of beefy flavor like (9 = like extremely; 1 = dislike extremely) for beef patties stratified by carcass treatment group (1 = control group; hot carcass lactic acid application only; 2 = hot water applied to hot carcass followed by hot carcass lactic acid application; 3 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter lactic acid spray; 4 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter acidified sodium chlorite spray; 5 = hot water applied to hot carcass followed by hot carcass lactic acid application, followed by a pre-fabrication cold forequarter Beefxide spray) and trimmings treatment group (A = trimmings sprayed with acidified sodium chlorite; B = trimmings sprayed with Beefxide; C = control, no antimicrobial application; L = trimmings sprayed with lactic acid). Means lacking a common letter (a-e) differ (P < 0.05).
